Wheel Locks - TDX SI & TDX SI-2 After 9/14/11

Print this page

Click to Enlarge

Item

Part/Kit

Part/Kit Description

Qty/Pkg

Qty/Asbly

MSRP

View Parts Notes

1173783

Item	Part/Kit Description	Qty/Pkg	Qty/Asbly
2	Bracket, Wheel Lock, Black - Right	1	1
3	Screw, Socket Head w/ Patch (5/16-18 x 7/8")	1	2
4	NLA - Screw, Hex Head w/ Patch (5/16-18 x 7/8")	1	2
5	Washer, Flat (5/16 x 5/8 x 1/16")	1	2
6	Locknut (5/16-18)	1	2
	Instruction Sheet, Installation	1	1
2	Bracket, Wheel Lock, Black - Right	1	1
3	Screw, Socket Head w/ Patch (5/16-18 x 7/8")	1	2
4	NLA - Screw, Hex Head w/ Patch (5/16-18 x 7/8")	1	2
5	Washer, Flat (5/16 x 5/8 x 1/16")	1	2
6	Locknut (5/16-18)	1	2
	Instruction Sheet, Installation	1	1

Kit, Wheel Lock Mounting Hardware - Right

Create/add to Wishlist

1173784

Item	Part/Kit Description	Qty/Pkg	Qty/Asbly
2	Bracket, Wheel Lock, Black - Left	1	1
3	Screw, Socket Head w/ Patch (5/16-18 x 7/8")	1	2
4	NLA - Screw, Hex Head w/ Patch (5/16-18 x 7/8")	1	2
5	Washer, Flat (5/16 x 5/8 x 1/16")	1	2
6	Locknut (5/16-18)	1	2
	Instruction Sheet, Installation	1	1
2	Bracket, Wheel Lock, Black - Left	1	1
3	Screw, Socket Head w/ Patch (5/16-18 x 7/8")	1	2
4	NLA - Screw, Hex Head w/ Patch (5/16-18 x 7/8")	1	2
5	Washer, Flat (5/16 x 5/8 x 1/16")	1	2
6	Locknut (5/16-18)	1	2
	Instruction Sheet, Installation	1	1

Kit, Wheel Lock Mounting Hardware - Left

Create/add to Wishlist

1139885

Wheel Lock Assembly - Right

$131.00

Create/add to Wishlist

1139886

Wheel Lock Assembly - Left

$110.00

Create/add to Wishlist

1101725

Cap, Brake Lever End, Black

$9.00

Create/add to Wishlist

1130584

Package, Cap, Brake Lever End, Black

$31.00

Create/add to Wishlist

Assembly Part Notes

Note Code	Definition
A	Includes items 2-6 and Installation Instruction Sheet.
B	Wheel Lock Assembly includes the Brake Lever End Cap item #8 part number 1101725.

Catalog Literature

Parts Books for TDX® SI, TDX® SI-2 TDX® SI-HD
